CE Cetificate Traffic Car Park Barriers With 6m Straight Arm Gate Barrier

CE Cetificate Traffic Vehicle Barrier Gate With 6m Straight Arm Gate Barrier





WONSUN SUMMER PROMOTION: 1.8S 304USD/Set

IF INTEREST, PLEASE CONTACT ME FREELY

SKYPE: zimin1314

Whatsapp: +86 18507481610





Quick details:



1) Beam length: <=6m

2) Opening (Closing) time: 1s, 1.8s,3s, 6s

3) Machine core working temperature: -40 degrees to +75 degrees

4) Electric working temperature: -20 degrees to +75 degrees

5) Rated voltage: AC 220V (10%) 50Hz/60Hz, 110V (10%) 50Hz/60Hz

6) Rated power: 120W

7) Relative humidity: <=90%

8) Remote control distance: <=30m

9) Net weight: 55KGS

10) Package size: 1035*375*475mm

Functions:

1) Manual release
2) Machine core with compression spring, effectively avoids the accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal radiating
4) Motor cooling fan, solving the problem of heat-protection
5) Double safety limit switches (photocell electrical limit switch/motor memory sensor)
6) Reversing on obstacle,Auto-closing
7) Support the INFRARER PHTOCELL for anti-bumping function (optional)
8) Support the external and internal VEHICLE LOOP DETECTOR (optional)
9) Traffic light interface
10) Wire control (switch signal)/ Remote control (418MHZ)
11) RS485 communication module (optional)



Highlight:

vehicle access control barriers

,

car parking management system

,

6m Car Park Barriers

Housing Material::
2mm Cold Roll Plate Or Galvanized Plate
Product Name::
CE Cetificate Traffic Vehicle Barrier Gate With 6m Straight Arm Gate Barrier
Color:
Yellow, Orange, Black, Blue, Customize Optional
Arm Length::
0.6s With 2.5m, 1s With 3m, 1.8s With 3.5m, 3s With 4.5m, 6s With 6m
OEM/ODM:
Supported
Operation Time::
0.6s, 1s, 1.8s, 3s, 6s, Optional
